Product Details:
|
| Product Code: | S-SFP-GE-LH40-SM1550 | Transceiver Form Factor: | ESFP |
|---|---|---|---|
| Transmission Speed: | 1 Gbit/s | Connector Type: | LC |
| Net Dimension(D X W X H Mm): | 110 X 70 X 37 | Shipment: | DHL,UPS,TNT, |
| Center Wavelength (nm): | 1550 | Warranty: | 1 Year |
| MOQ: | 1PC | ||
| High Light: | Networking Huawei SFP Module,Huawei S-SFP-GE-LH40-SM1550,Huawei SFP Optical Transceiver Module |
||
S-SFP-GE-LH40-SM1550
Huawei S-SFP-GE-LH40-SM1550 is Optical Transceiver. It’s a Single-mode Module.
S-SFP-GE-LH40-SM1550 Specification |
|
| Transceiver form factor | eSFP |
| Transmission speed | 1 Gbit/s |
| Center wavelength (nm) | 1550 |
| Standard compliance | 1000base-LX/LH |
| Connector type | LC |
| Applicable cable and maximum transmission distance | Single-mode fiber: 40 km |
| Transmit power (dBm) | -5.0 to 0 |
| Maximum receiver sensitivity (dBm) | -22 |
| Overload power (dBm) | -3.0 |
| Extinction ratio (dB) | 8.5 |
| Operating temperature | 0°C to 70°C (32°F to 158°F) |
| Net Dimension(D x W x H mm) | 110 x 70 x 37 |
