Product Details:
|
| Name: | ISR4221-SEC/K9 35Mbps-75Mbps System Throughput SEC Bundle SEC Lic 2 NIM | Product Model: | ISR4221-SEC/K9 |
|---|---|---|---|
| Forwarding Performance: | 132 Mpps | Switching Capacity2: | 176 Gbit/s/432 Gbit/s |
| Fixed Ports: | 48 X 10/100/1000BASE-T Ports, 4 X 10 GE SFP+ Ports | PoE+: | Supported |
| Port: | Shanghai | Keywords: | Cisco Catalyst C4300 Switches |
| High Light: | ISR4221-SEC/K9 SEC Bundle,35Mbps System Throughput SEC Bundle,SEC Lic 2 NIM Network Router |
||
Cisco ISR4221-SEC/K9 Specification |
|
|
Bundle |
Cisco ISR 4221 SEC Bundle with SEC lic |
|
Aggregate Throughput |
35 Mbps to 75 Mbps |
|
Total onboard WAN or LAN 10/100/1000 ports |
2 |
|
RJ-45-based ports |
2 |
|
SFP-based ports |
1 |
|
Enhanced service-module slots |
0 |
|
Doublewide service-module slots |
0 |
|
NIM slots |
2 |
|
OIR (all I/O modules) |
No |
|
Onboard ISC slot |
No |
|
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes) |
4 GB |
|
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes) |
4 GB |
|
Default memory DDR3 ECC DRAM (data plane) |
NA |
|
Maximum memory DDR3 ECC DRAM (data plane) |
NA |
|
Default memory DDR3 ECC DRAM (control/services plane) |
NA |
|
Maximum memory DDR3 ECC DRAM (control/services plane) |
NA |
|
Default flash memory |
8 GB |
|
Maximum flash memory |
8 GB |
|
External USB 2.0 slots (type A) |
1 |
|
USB console port -type B mini (up to 115.2 kbps) |
0 |
|
Serial console port - RJ45 (up to 115.2 kbps) |
1 (combo CON/AUX port) |
|
Serial auxiliary port - RJ45 (up to 115.2 kbps) |
1 (combo CON/AUX port) |
|
Power-supply options |
External: AC Only |
|
Redundant power supply |
N/A |
|
AC input voltage |
100 to 240 VAC autoranging |
|
AC input frequency |
47 to 63 Hz |
|
AC input current range, AC power supply (maximum) |
1.5 to 0.6A |
|
AC input surge current |
90 A peak and less than 3 Arms per half cycle |
|
Typical power (no modules) (watts) |
24 |
|
Maximum power with AC power supply (watts) |
90 |
|
Maximum power with PoE power supply (platform only) (watts) |
NA (no PoE support) |
|
Maximum endpoint PoE power available from PoE power supply (watts) |
NA (no PoE support) |
