C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G

C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G
C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G

Large Image :  C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G

Product Details:
Place of Origin: China
Brand Name: Cisco
Certification: CE
Model Number: C1000-48FP-4X-L
Contact Now

C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G

Description
Name: C1000-48FP-4X-L Model: C1000-48FP-4X-L
Gigabit Ethernet Ports: 48 Availability: In Stock
Condition: New Warranty: 1 Years
DRAM: 512 MB Switching Bandwidth: 176 Gbps
CPU: ARM V7 800 MHz Fanless: N
Highlight:

Cisco 1000 Series Ethernet Switch

,

48-port PoE switch with 10G

,

740W Cisco switch with warranty

C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G

C1000-48FP-4X-L Overview

Cisco® Catalyst® 1000 Series Switches are fixed managed Gigabit Ethernet enterprise-class Layer 2 switches designed for small businesses and branch offices. These are simple, flexible and secure switches ideal for out-of-the-wiring-closet and critical Internet of Things (IoT) deployments. Cisco® Catalyst® 1000 operate on Cisco IOS® Software and support simple device management and network management via a Command-Line Interface (CLI) as well as an on-box web UI. These switches deliver enhanced network security, network reliability, and operational efficiency for small organizations.

C1000-48FP-4X-L Specification

C1000-48FP-4X-L Specification
Description 48x 10/100/1000 Ethernet PoE+ ports and 740W PoE budget, 4x 10G SFP+ uplinks
Gigabit Ethernet ports 48
Uplink interfaces 4 SFP+
PoE+power budget 740W
Fanless N
Dimensions (WxDxH in inches) 17.5 x 13.78 x 1.73
Console ports
RJ-45 Ethernet 1
USB mini-B 1
USB-A port for storage and Bluetooth console 1
Memory and processor
CPU ARM v7 800 MHz
DRAM 512 MB
Flash memory 256 MB
Performance
Forwarding bandwidth 88 Gbps
Switching bandwidth 176 Gbps
Forwarding rate(64—byte L3 packets) 77.38 Mpps
Unicast MAC addresses 16000
IPv4 unicast direct routes 542
IPv4 unicast indirect routes 256
IPv6 unicast direct routes 414
IPv6 unicast indirect routes 128
IPv4 static routes 16
IPv6 static routes 16
IPv4 multicast routes and IGMP groups 1024
IPv6 multicast groups 1024
IPv4/MAC security ACEs 600
IPv6 security ACEs 600
Maximum active VLANs 256
VLAN IDs available 4094
Maximum STP instances 64
Maximum SPAN sessions 4
MTU-L3 packet 9198 bytes
Jumbo Ethernet frame 10,240 bytes
Dying Gasp Yes
MTBF in hours (data) 1,452,667
MTBF in hours (PoE) 856,329
MTBF in hours (Full PoE) 856,329
Environmental
Operating temperature Seal level -5 to 50 deg C*
Up to 5,000ft (1500 m) -5 to 45 deg C
Upto 10,000 (3000 m) -5 to 40 deg C
Operating altitude 10,000 ft (3,000m)
Operating relative humidity 5% to 90% at 40C
Storage temperature -13 to 158F (-25 to 70C)
Storage altitude 15,000 ft (4500m)
Storage relative humidit 5% to 95% at 65C

*Note:

50C operation is supported for short term operation only; GLC-BX-D/U and CWDM optics cannot support 50C operation; Minimum ambient temperature for cold start is at 0C (32F)
Safety and compliance
Safety

UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1, IEC 62368-1, UL 62368-1

GB 4943.1-2011

EMC: Emissions



 47CFR Part 15 Class A, AS/NZS CISPR32 Class A, CISPR32 Class A, EN55032 Class A, ICES-003 Class A, VCCI-CISPR32 Class A, EN61000-3-2, EN61000-3-3, KN32 Class A, CNS13438 Class A
EMC: Immunity EN55024 (including EN 61000-4-5), EN300386, KN35
Environmental Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU
Telco Common Language Equipment Identifier (CLEI) code
U.S. government certifications TBD
Connectors and interfaces

Ethernet interfaces





* 10BASE-T ports: RJ-45 connectors, 2-pair Category 3, 4, or 5 Unshielded Twisted Pair (UTP) cabling

* 100BASE-TX ports: RJ-45 connectors, 2-pair Category 5 UTP cabling

* 1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling

* 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Category 5 UTP cabling

Indicator LEDs



* Per-port status: link integrity, disabled, activity

* System status: system

Console cables



* CAB-CONSOLE-RJ45 Console cable 6 ft. with RJ-45

* CAB-CONSOLE-USB Console cable 6 ft. with USB Type A and mini-B connectors

Power



* Use the supplied AC power cord to connect the AC power connector to an AC power outlet

* Models have external power supply



C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G 0C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G 1C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G 2C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G 3C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G 4C1000-48FP-4X-L New 1000 Series Switches 48 ports 10/100/1000 Ethernet PoE and 740W 4x 10G 5
