Product Details:
|
| Name: | Huawei CE6865E-48S8CQ-B Enterprise Switch High Quality AC Power Modules | Model: | CE6865E-48S8CQ-B |
|---|---|---|---|
| Forwarding Performance: | 24 Mpps | Switching Capacity2: | 32 Gbit/s/336 Gbit/s |
| Warranty: | 1 Year | PoE+: | Supported |
| Fixed Ports: | 12 X 10/100/1000Base-T Ports, 4 X GE SFP Ports | Port: | Shanghai |
| Item | Description |
| Processor | 1.4 GHz, four-core |
| DRAM Memory | 4 GB |
| NOR Flash | 64 MB |
| NAND Flash | 4 GB |
| Mean time between failures (MTBF) | 45.48 years |
| Mean time to repair (MTTR) | 1.52 hours |
| Fixed ports | Forty-eight 10GE SFP+ Ethernet optical ports Six 40GE/100GE QSFP28 Ethernet optical ports |
| Physical specifications | Dimensions (H x W x D): 43.6 mm x 442.0 mm x 420.0 mm |
| Temperature |
Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.) Storage temperature: -40°C to +70°C (-40°F to +158°F) |
| Relative humidity | 5% RH to 95% RH, noncondensing |
| Altitude | < 5000 m (16404 ft.) |
| Noise (sound pressure, 27°C) | Back-to-front airflow: < 55 dBA; Front-to-back airflow: < 55 dBA |
| Power source type | AC/DC/HVDC |
| AC power input |
Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz |
| DC power input |
Rated voltage range: -48 V DC to -60 V DC Maximum voltage range: -38.4 V DC to -72 V D |
| High-voltage DC power input |
Rated voltage range: -48 V DC to -60 V DC Maximum voltage range: 190 V DC to -290 V D |
| Rated input current |
600 W AC&240 V DC power (PAC600S12 series): 8 A (100 V AC to 240 V AC); 4 A (240V DC) 1000 W DC power (PDC1000S12 series): 30 A (-48 V DC to -60 V DC) |
| Maximum power consumption | 282 W |
| Typical power consumption |
162 W (100% throughput, SFP+ high-speed cables on 48 ports and QSFP28 high-speed cables on 6 ports, double power modules) 196 W (100% throughput, all optical interfaces on the switch are equipped with the short-distance optical modules, double power modules) |
| Maximum heat dissipation | 962 BTU/Hr |
| Heat dissipation mode | Air cooling |
| Airflow | Front-to-back or back-to-front, depending on the fan modules and power modules |
| Power module backup | 1+1 backup |
| Fan module backup | 3+1 backup |
| Hot swap | Supported by all power modules and fan modules |
| Availability | 0.99999618 |
| Service port supporting the stack function | 10GE optical ports, and 100GE optical ports |
