Product Details:
|
| Name: | S5735-L24P4S-A 24 Port POE Gigabit Ethernet S5735 Power Supply Switch | Model: | S5735-L24P4S-A |
|---|---|---|---|
| Forwarding Performance: | 24 Mpps | Switching Capacity2: | 32 Gbit/s/336 Gbit/s |
| Warranty: | 1 Year | PoE+: | Supported |
| Fixed Ports: | 12 X 10/100/1000Base-T Ports, 4 X GE SFP Ports | Port: | Shanghai |
| High Light: | S5735 Power Supply Switch,POE Gigabit Ethernet Switch |
||
S5735-L24P4S-A is the Huawei S5735-L switch with 24 x 10/100/1000Base-T ports, 4 x GE SFP ports, PoE+. Huawei CloudEngine S5735-L is a series of simplified gigabit access switches that provide 12–48 flexible all-GE downlink ports and four fixed GE or 10 GE uplink ports. They are designed for enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and powered by Huawei’s Versatile Routing Platform (VRP), CloudEngine S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols — providing higher performance and more powerful service processing capabilities for networks.
S5735-L24P4S-A Specification |
|
| Forwarding Performance | 42 Mpps |
| Switching Capacity2 | 56 Gbit/s/336 Gbit/s |
| Fixed Ports | 24 x 10/100/1000Base-T ports, 4 x GE SFP ports |
| PoE+ | Supported |
| MAC Features | MAC address auto-learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC address learning limiting |
| VLAN Features | 4094 VLANs Guest VLAN, Voice VLAN GVRP MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping |
| IP Routing | Static route, RIP, RIPng, OSPF, OSPFv3 |
| Super Virtual Fabric (SVF) | Plug-and-play SVF clients Automatic software package and patch loading to SVF clients One-click and automatic delivery of service configurations Independent SVF client operations |
| Interoperability | VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP) |
