N9K-C9332C - Cisco Nexus Ethernet Switch 9000 Series Gigabit Nintendo

N9K-C9332C Specification

● 32-port 40/100G QSFP28 ports & 2-port 1/10G SFP+ ports

● 1100 watt (W) AC, DC or HVAC/HVDC power supplies (up to 2)

● Hot-swappable, 5 fans with redundancy

● System memory: 16 GB

● SSD: 256GB

● USB: 1 port

● RS-232 serial console ports: 1

● Management ports:
2 (1 x 10/100/1000BASE-T and 1 x 1-Gbps SFP+)

● Broadwell-DE CPU: 4 cores

● Power: 1100W AC, 1100 DC or 1100W HVAC/HVDC

● Input voltage: 100 to 240V* AC or -40V to -72V DC (min‑max), -48V to -60V DC (nominal)

*Supports input voltage of 100-120V for a max output of 800W; 200-240V for a max output of 1200W

● Frequency: 50 to 60 Hz (AC)

● Efficiency: 90% or greater
(20 to 100% load)

● RoHS compliance: Yes

● Hot swappable: Yes

● Port-side intake or port-side exhale options

● Typical power: 296W (AC)

● Maximum power: 700W (AC)

● Physical (H x W x D): 1.7 x 17.3 x 22.9 in. (4.4 x 43.9 x 58.1 cm)

● Weight: 25.1lb (11.4kg) with power supplies and fans, 19 lb (8.6kg) without power supplies and fans

● Operating temperature: 32 to 104°F (0 to 40°C)

● Nonoperating (storage) temperature: -40 to 158°F (-40 to 70°C)

● Humidity: 5 to 85% (noncondensing)

● Altitude: 0 to 13,123 ft (0 to 4000m)

● Fan speed at 50%: 76.4 dBA

● Fan speed at 70%: 83.3 dBA

● Fan speed at 100%: 92.1 dBA

● 36-port 40G QSFP ports

● 1200 watt (W) AC power supplies or 930W DC power supplies (up to 2)

● 80 Plus Platinum-rated power supplies that provide at least 90% efficiency with 20% utilization

● Hot-swappable, dual fan trays with redundant fans

● Port-side intake or Port side exhaust airflow direction

● System memory: 16GB

● SSD: 64GB

● USB: 2 ports

● RS-232 serial console ports: 1

● Management ports: 1 x 10/100/1000BASE-T

● 32-port 40/100G QSFP28 ports & 2-port 1/10G SFP+ ports

● 1100 watt (W) AC, DC or HVAC/HVDC power supplies (up to 2)

● Hot-swappable, 5 fans with redundancy

● System memory: 16 GB

● SSD: 256GB

● USB: 1 port

● RS-232 serial console ports: 1

● Management ports:

2 (1 x 10/100/1000BASE-T and 1 x 1-Gbps SFP+)

● Broadwell-DE CPU: 4 cores
