Product Details:
|
| Model: | QSFP-40G-iSR4 | Name: | Huawei QSFP - 40G - ISR4 Optical Transceiver Best Price |
|---|---|---|---|
| Detail: | 40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(Connect To Four SFP+ Optical Transceiver) | MOQ: | 1 |
| Port: | Shanghai | Condition: | Original New |
| Form Type: | QSFP+ | Cable Type: | MMF |
| High Light: | QSFP-40G-ISR4 Huawei SFP Module,Optical Huawei SFP Module,Huawei SFP Optical Module |
||
Huawei QSFP - 40G - iSR4 Optical Transceiver best price
| Product Code | QSFP-40G-iSR4 |
| Part Number | 02310MHR |
| Description | 40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(Connect to four SFP+ Optical Transceiver) |
| Form Type | QSFP+ |
| Wavelength | 850nm |
| Interface | MTP/MPO |
| Cable Type | MMF |
| CDR Support | Yes |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Max Data Rate | 40Gbps |
| Max Cable Distance* | 150m** |
| Optical Components | VCSEL 850nm |
| DOM Support | NO |
| Protocols | 40G Ethernet, Infiniband QDR, SATA/SAS3, IEEE 802.3ba |
the comparison of QSFP-40G-ER4, QSFP-40G-iSR4 and QSFP-40G-LR4.
| Product Code | QSFP-40G-ER4 | QSFP-40G-iSR4 | CFP-40G-LR4 |
| Part Number | 02311BKT | 02310MHR | 02310MHS |
| Description | 40GBase-ER4 Optical Transceiver,QSFP+,40G,Single-mode Module (1310nm,40km,LC) | 40GBase-iSR4 Optical Transceiver,QSFP+,40G,Multi-mode (850nm,0.15km,MPO)(Connect to four SFP+ Optical Transceiver) | 40GBase-LR4 Optical Transceiver,QSFP+,40GE,Single-mode Module(1310nm,10km,LC) |
| Form Type | QSFP+ | QSFP+ | QSFP+ |
| Wavelength | 1310nm | 850nm | 1310nm |
| Max Data Rate | 44.6Gbps | 40Gbps | 44.6Gbps |
| Max Cable Distance* | 40km** | 150m** | 10km |
