Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram

Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram
Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram

Large Image :  Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram

Product Details:
Place of Origin: CHINA
Brand Name: CISCO
Certification: CE
Model Number: CISCO1921/K9
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: NEW IN BOX
Delivery Time: 1-2 DYAS
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 50 UNITS/MONTH

Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram

Description
Brand: CISCO Model: CISCO1921/K
Warranty: 1 YEAR Interface Types: USB 2.0, Ethernet RJ45
Electrical Interface: Ethernet Gigabit - 1Gbps On-Board Cache: 512MB
Bays/Ports/Slots: 2 U Height: 1U
High Light:

cisco ethernet router

,

cisco modular router







CISCO1921/K9 Integrated Service Router, 2 GE, 2 EHWIC slots, 512DRAM, IP Base



CISCO1921/K9 Overview



Cisco CISCO1921/K9 1921 / 1900 ISR - 2 GE, 2 EHWIC slots, 512MB DRAM, 256MB Flash, IP Base - Brand New



Cisco CISCO1921/K9 1921 / 1900 Integrated Service Router - 2 Gigabit Ethernet, 2Enhanced High-speed WAN Interface Card slots, 512MB DRAM, 256MB Flash, Internet Protocol Base - Brand New



The Cisco 1921 builds on the best-in-class. All Cisco 1900 Series Integrated Services Routers offer embedded hardware encryption acceleration, and advanced security services. In addition, the platforms support the industry's widest range of wired and wireless connectivity options such as Serial, T1/E1, xDSL, Gigabit Ethernet, and third-generation (3G) wireless.



The Cisco 1921 is architected to meet the application demands of today's branch offices with design flexibility for future applications.



The Cisco 1921 provides significantly enhanced modular capabilities that offer you investment protection. You can easily interchange modules used on the Cisco 1921 with other Cisco routers to provide maximum investment protection. Taking advantage of common interface cards across a network greatly reduces the complexity of managing inventory requirements, implementing large network rollouts, and maintaining configurations across a variety of branch-office sizes.







Cisco1921 / K9 Integrated Services Router Ip Base 2 Ge 2 Ehwic Slots 512dram 0





CISCO1921/K9 Specification





Cisco 1921 Integrated Service Routers
Model Number CISCO1921/K9
Product SPECIFICATIONS
Services and Slot Density
Embedded Hadware-based cryptoghraphy acceleration (IPsec + SSL) Yes
RJ-45 onboad LAN/WAN 10/100/1000 ports 2
EHWIC slots 2
Doublewide EHWIC slots (use of a double EHWIC slot will consume 2 EHWIC slots) 1
Cisco Integrated Servikces Module (ISM) slots 0
Memopry (DDR2 DRAM: Default/maximum 512 MB/512 MB
USB flash memory (internal: Default/maximum 256 MB/256 MB
External USB flash-memory slots (Type A) 1
USB console (mini-Type B)(up to 115.2 kbps) No
Serial console (up to 115.2 kbps) 1
Serial auxiliary port (up to 115.2 kbps) 1
Integrated power supply AC and DC power-supply models
Power-supply options Poe (external) - on AC models only
Redundant-power-supply support No
Power Specification
AC input voltage 100-240V
AC input frequency 47-63 Hz
AC input current range AC power suppy (maximum) (amps) 1.5 - 0.6
AC input surge current <50A
Typical power (no module 215W
Maximum power capacity with AC power supple 60W
Maximum power capacity with PoE power supply (platform only) 70W
Maximum PoE device power capacity with PoE power supply 80W
DC power input 32-60 VDC
  • 4A
  • positive or negative
    single source
DC input wire sized AG 14 (2.0 mm2
Safety ground-wire size AWG 14 (2.0 mm2), minimum
Wire terminal (lug) Amp/Tyco No. 32957
overcurrent portection 20A maximum
Physical Specification
Dimensions (H x W x D) 1.75 x 13.5 x 11.5 in
(4.45 x 34.29 x 29.21 cm)
Rack height 1 rack unit (1RU)
Rack-mount 19 in. (48.3 cm) EIA Optional
Wall-mount (refer to installation guide for approved orientation) Yes
Weight: With AC power supply (no modules) 6.75 lbs
Weight: With PoE poewr supply (no modules) 7.5 lb
Airflw Back to sides
Environmental Specificatoins
operating Conditions
Temperature: 5906 ft (1800m) maximum altitude 32-104°F
(0-40°C)
Temperature: 9843 ft (3000m) maximum altitude 32-77°F
(0-25°C)
Altitude 10,000 ft
(3,000m)
Humidity 10 to 85% relative humidity (RH)
Acoustic: Sound pressure (typical/maximum) 32.99/58.33 dBA
Acoustic: Sound power (typical/maximum) 41.99/67.22 dBA/td>
Transportation and Storage Conditions
Temperatire -40 to 158°F
(-40 to 70°C)
Humidity 5 to 95% RH
Altitude 15,000 ft
(4,570m)
Regulatory Compliance
Safety
  • UL 60950-1
  • CAN/CSA C22.2 No. 60950-1
  • EN 60950-1
  • AS/NZS 60950-1
  • IEC 60950-1
  • /td>
EMC
  • 47 CFR, Part 15
  • ICES-003 Class A
  • EN55022 Class A
  • CISPR22 Class A
  • AS/NZS 3548 Class A
  • VCCI V-3
  • EN 300-386
  • EN 61000 (Immunity)
  • EN 55024, CISPR 24
  • EN50082-1
Telcom
  • TIA/EIA/IS-968
  • CS-03
  • ANSI T1.101
  • IEEE 802.3
  • RTTE Directive
