Product Details:
|
| Brand: | CISCO | Model: | CISCO1921/K |
|---|---|---|---|
| Warranty: | 1 YEAR | Interface Types: | USB 2.0, Ethernet RJ45 |
| Electrical Interface: | Ethernet Gigabit - 1Gbps | On-Board Cache: | 512MB |
| Bays/Ports/Slots: | 2 | U Height: | 1U |
| High Light: | cisco ethernet router,cisco modular router |
||
CISCO1921/K9 Integrated Service Router, 2 GE, 2 EHWIC slots, 512DRAM, IP Base
Cisco CISCO1921/K9 1921 / 1900 ISR - 2 GE, 2 EHWIC slots, 512MB DRAM, 256MB Flash, IP Base - Brand New
Cisco CISCO1921/K9 1921 / 1900 Integrated Service Router - 2 Gigabit Ethernet, 2Enhanced High-speed WAN Interface Card slots, 512MB DRAM, 256MB Flash, Internet Protocol Base - Brand New
The Cisco 1921 builds on the best-in-class. All Cisco 1900 Series Integrated Services Routers offer embedded hardware encryption acceleration, and advanced security services. In addition, the platforms support the industry's widest range of wired and wireless connectivity options such as Serial, T1/E1, xDSL, Gigabit Ethernet, and third-generation (3G) wireless.
The Cisco 1921 is architected to meet the application demands of today's branch offices with design flexibility for future applications.
The Cisco 1921 provides significantly enhanced modular capabilities that offer you investment protection. You can easily interchange modules used on the Cisco 1921 with other Cisco routers to provide maximum investment protection. Taking advantage of common interface cards across a network greatly reduces the complexity of managing inventory requirements, implementing large network rollouts, and maintaining configurations across a variety of branch-office sizes.
| Cisco 1921 Integrated Service Routers | |
|---|---|
| Model Number | CISCO1921/K9 |
| Product SPECIFICATIONS | |
| Services and Slot Density | |
| Embedded Hadware-based cryptoghraphy acceleration (IPsec + SSL) | Yes |
| RJ-45 onboad LAN/WAN 10/100/1000 ports | 2 |
| EHWIC slots | 2 |
| Doublewide EHWIC slots (use of a double EHWIC slot will consume 2 EHWIC slots) | 1 |
| Cisco Integrated Servikces Module (ISM) slots | 0 |
| Memopry (DDR2 DRAM: Default/maximum | 512 MB/512 MB |
| USB flash memory (internal: Default/maximum | 256 MB/256 MB |
| External USB flash-memory slots (Type A) | 1 |
| USB console (mini-Type B)(up to 115.2 kbps) | No |
| Serial console (up to 115.2 kbps) | 1 |
| Serial auxiliary port (up to 115.2 kbps) | 1 |
| Integrated power supply | AC and DC power-supply models |
| Power-supply options | Poe (external) - on AC models only |
| Redundant-power-supply support | No |
| Power Specification | |
| AC input voltage | 100-240V |
| AC input frequency | 47-63 Hz |
| AC input current range AC power suppy (maximum) (amps) | 1.5 - 0.6 |
| AC input surge current | <50A |
| Typical power (no module | 215W |
| Maximum power capacity with AC power supple | 60W |
| Maximum power capacity with PoE power supply (platform only) | 70W |
| Maximum PoE device power capacity with PoE power supply | 80W |
| DC power input | 32-60 VDC
|
| DC input wire sized | AG 14 (2.0 mm2 |
| Safety ground-wire size | AWG 14 (2.0 mm2), minimum |
| Wire terminal (lug) | Amp/Tyco No. 32957 |
| overcurrent portection | 20A maximum |
| Physical Specification | |
| Dimensions (H x W x D) | 1.75 x 13.5 x 11.5 in (4.45 x 34.29 x 29.21 cm) |
| Rack height | 1 rack unit (1RU) |
| Rack-mount 19 in. (48.3 cm) EIA | Optional |
| Wall-mount (refer to installation guide for approved orientation) | Yes |
| Weight: With AC power supply (no modules) | 6.75 lbs |
| Weight: With PoE poewr supply (no modules) | 7.5 lb |
| Airflw | Back to sides |
| Environmental Specificatoins | |
| operating Conditions | |
| Temperature: 5906 ft (1800m) maximum altitude | 32-104°F (0-40°C) |
| Temperature: 9843 ft (3000m) maximum altitude | 32-77°F (0-25°C) |
| Altitude | 10,000 ft (3,000m) |
| Humidity | 10 to 85% relative humidity (RH) |
| Acoustic: Sound pressure (typical/maximum) | 32.99/58.33 dBA |
| Acoustic: Sound power (typical/maximum) | 41.99/67.22 dBA/td> |
| Transportation and Storage Conditions | |
| Temperatire | -40 to 158°F (-40 to 70°C) |
| Humidity | 5 to 95% RH |
| Altitude | 15,000 ft (4,570m) |
| Regulatory Compliance | |
| Safety |
|
| EMC |
|
| Telcom |
|
