Product Details:
|
Name: | S5735-L24T4X-A | Model: | S5735-L24T4X-A - Huawei S5735-L Switches |
---|---|---|---|
Availability: | Stock | Condition: | New Factory Sealed |
Warranty: | 1 Years | Forwarding Performance: | 42 Mpps |
Switching Capacity2: | 56 Gbit/s/336 Gbit/s | PoE+: | Supported |
Color: | Black | ||
High Light: | 1000Base-T Huawei Network Switches,42 Mpps Switch Network Device |
Product Model | S5735-L24T4X-A |
Forwarding Performance | 96 Mpps |
Switching Capacity2 | 128 Gbit/s/336 Gbit/s |
Fixed Ports | 24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports |
PoE+ | Not supported |
Supported Transceivers
Model | Description |
OMXD30000 | Huawei Optical Transceiver OMXD30000, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
OSX010000 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
SFP-GE-LX-SM | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
OSXD22N00 | Optical Transceiver, SFP+, 10G, Multi-mode Module (1310nm, 0.22km, LC, LRM) |
SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
OMXD30009 | Transceiver, QSFP+, 1310nm, 41.25Gbps, -7dBm, 2.3dBm, -11.5dBm, LC, SMF, 10 |
SFP-10G-LR | Huawei Optical Transceiver SFP-10G-LR, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
S5735-L24T4X-A Specification |
|
Forwarding Performance | 96 Mpps |
Switching Capacity2 | 128 Gbit/s/336 Gbit/s |
Fixed Ports | 24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports |
PoE+ | Not supported |
MAC Features | MAC address auto-learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC address learning limiting |
VLAN Features | 4094 VLANs Guest VLAN, Voice VLAN GVRP MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping |
IP Routing | Static route, RIP, RIPng, OSPF, OSPFv3 |
Super Virtual Fabric (SVF) | Plug-and-play SVF clients Automatic software package and patch loading to SVF clients One-click and automatic delivery of service configurations Independent SVF client operations |
Interoperability | VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP) |
