Product Details:
|
| Brand: | Cisco | Model: | AIR-PWRINJ1500-2 |
|---|---|---|---|
| Product Type: | PoE Injector | Connector Type: | RJ-45 |
| Voltage Provided: | AC 100-240 V | Warranty: | New And Original With 1year |
| Highlight: | fiber optic transceiver,optical fiber transceiver |
||
AIR-PWRINJ1500-2 Cisco Power Supply 1520 Series Power Injector with AC 100-240 V
1.Overview
When a Cisco Aironet 1520 Series access point is installed on the roof of a building, power can be supplied over Ethernet using a power injector. The power injector converts AC power into DC power and sends it along with the Ethernet signal to the access point. Use the Cisco Aironet 1520 Series Power Injector, along with any standard outdoor rated Ethernet cable, to power the access point. Do not use any power injector other than the onespecified. You will need to specify the country-specific power cord with the power injector.
2. Specifications
| Input voltage | 100 to 240 VAC |
| Output voltage | 56.0 VDC |
| Voltage range tolerance | 54 VDC to 57 VDC |
| Maximum current | 1.43 A |
| No load current | 15 mA |
| Output 1 voltage and current | 56VDC@0.71A Pin 3, 6—+56VDC Pin 1, 2—Return |
| Output 2 voltage and current | 56VDC@0.71A Pin 4, 5—+56VDC Pin 7, 8—Return |
| Operating temperature | -40 to 131 degrees F (-40 to 55 degrees C) |
| Storage temperature | -58 to 185 degrees F (-50 to 85 degrees C) |
| Operating humidity | 10% to 90% non-condensing |
| Storage humidity | 10% to 95% non-condensing |
| Length | 8 in.(20.3 cm) |
| Width | 4.25 in.(10.8 cm) |
| Height | 2.5 in. (6.3 cm) |
Shows Power Injector Connections
| 1 | Mounting tabs |
4
|
AC POWER LED |
| 2 | AP POWER LED |
5 |
TO AP—RJ-45 connection to access point (10/100/1000Base-T) |
| 3 | FAULT LED |
6
|
TO SWITCH—RJ-45 connection to switch (10/100/1000Base-T) |
The following items are shipped with the power injector:
