CE5810-48T4S-EI Specification
|
|
Switching Capacity
|
176 Gbit/s
|
|
Forwarding Rates
|
132 Mpps
|
|
Airflow Design
|
Front-to-back or back-to-front
|
|
Device Virtualization
|
iStack
|
|
Super Virtual Fabric (SVF)
|
|
Network Virtualization
|
M-LAG
|
|
TRILL (CE5855 & CE5850)
|
|
VM Awareness
|
Agile Controller
|
|
SDN
|
Open Programmability System (OPS)
|
|
Traffic Analysis
|
NetStream
|
|
sFlow
|
|
VLAN
|
Adding access, trunk, and hybrid interfaces to VLANs
|
|
Default VLAN
|
|
QinQ
|
|
MUX VLAN
|
|
GVRP
|
|
ACL
|
ingress: 4.5k
egress: 1k
|
|
MAC Address Table
|
maximum: 32k
|
|
Dynamic learning and aging of MAC addresses
|
|
Static, dynamic, and black hole MAC address entries
|
|
Packet filtering based on source MAC addresses
|
|
MAC address limiting based on ports and VLANs
|
|
ARP (maximum)
|
8k
|
|
IPv4 FIB (maximum)
|
12k
|
|
IP Routing
|
IPv4 routing protocols, such as RIP, OSPF, BGP, and IS-IS
|
|
IPv6 routing protocols, such as RIPng, OSPFv3, IS-ISv6, and BGP4+ (not supported by CE5855)
|
|
IPv6 FIB (maximum)
|
6k
|
|
IPv6
|
IPv6 Neighbor Discovery (ND) (not supported by CE5855)
|
|
Path MTU Discovery (PMTU) (not supported by CE5855)
|
|
TCP6, ping IPv6, tracert IPv6, socket IPv6, UDP6, and Raw IP6
|
|
Multicast FIB (maximum)
|
8k
|
|
Multicast
|
IGMP, PIM-SM, PIM-DM, MSDP, and MBGP
|
|
IGMP snooping
|
|
IGMP proxy
|
|
Fast leave of multicast member interfaces
|
|
Multicast traffic suppression
|
|
Multicast VLAN
|
|
Reliability
|
LACP
|
|
STP, RSTP, VBST, MSTP
|
|
BPDU protection, root protection, and loop protection
|
|
Smart Link and multi-instance
|
|
DLDP
|
|
ERPS (G.8032)
|
|
VRRP, VRRP load balancing, and BFD for VRRP
|
|
BFD for BGP/IS-IS/OSPF/Static route
|
|
QoS
|
Traffic classification based on Layer 2 headers, Layer 3 protocols, Layer 4 protocols, and 802.1p priority
|
|
Actions of ACL, CAR, re-marking, and scheduling
|
|
Queue scheduling algorithms, including PQ, WRR, DRR, PQ + WRR, and PQ + DRR
|
|
Congestion avoidance mechanisms, including WRED and tail drop
|
|
Traffic shaping
|
|
Configuration and Maintenance
|
Console, Telnet, and SSH terminals
|
|
Network management protocols, such as SNMPv1/v2c/v3
|
|
File upload and download through FTP and TFTP
|
|
BootROM upgrade and remote upgrade
|
|
802.3az Energy Efficient Ethernet (EEE)
|
|
Hot patches
|
|
User operation logs
|
|
Zero-Touch Provisioning (ZTP)
|
|
Security and Management
|
802.1x authentication
|
|
Command line authority control based on user levels, preventing unauthorized users from using commands
|
|
DoS, ARP, and ICMP attack defenses
|
|
Port isolation, port security, and sticky MAC
|
|
Binding of the IP address, MAC address, interface number, and VLAN ID
|
|
Authentication methods, including AAA, RADIUS, and HWTACACS
|
|
Remote Network Monitoring (RMON)
|
|
Environmental Parameters
|
Operating temperature: 0°C to 40°C (32°F to 104°F) (0m to 1,800m)
|
|
Storage temperature: -40°C to 70°C (-40°F to 158°F)
|
|
Relative humidity: 5% to 95%, non-condensing
|
|
Operating Voltage
|
AC: 90V to 290V
|
|
DC: -38.4V to -72V
|
