Product Details:
|
| Name: | C9500-40X-A | Model: | C9500 40X A Cisco Switch Catalyst 9500 |
|---|---|---|---|
| Product Code: | C9500 40X A | Switching Capacity: | Up To 960 Gbps |
| Warrranty: | 1 Year | Shipping: | DHL&FeDex |
| AC Power Max Rating: | 950W | System Power Consumption: | 850W Max |
| Dimensions (H X W X D): | 1.73 X 17.5 X 21.52 In | Rack Units (RU): | 1 RU |
| Highlight: | Network Advantage Cisco Switch Catalyst 9500,40X Cisco Switch Catalyst 9500,10Gig Cisco Switch Catalyst 9500 |
||
C9500-40X-A is one of the the Cisco Catalyst 9500 Series Switches. The Cisco Catalyst 9500 Series Switches are the next generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on an x86 CPU, the Catalyst 9500 Series is Cisco's lead purpose-built fixed core and aggregation enterprise switching platform, built for security, IoT, and cloud. The Catalyst 9500 Series is the industry's first purpose-built 40 Gigabit Ethernet line of switches targeted for the enterprise campus.
Table 1 shows the Quick Specs.
| Product Code | C9500-40X-A |
| Description | Catalyst 9500 40-port 10Gig switch, Network Advantage |
| Switching capacity | Up to 960 Gbps |
| Forwarding rate | Up to 720 Mpps |
| AC power max rating | 950W |
| System power consumption | 850W max |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in |
| Rack units (RU) | 1 RU |
Figure 2 shows the front panel of C9500-40X-A.
Note:
| ① | 40 10G SFP ports |
| ② | Network modules |
| ③ | RFID |
| ④ | Console port (RJ-45 Serial) |
| ⑤ | Blue beacon LED |
| ⑥ | USB mini Type B console port |
| ⑦ | Mode button |
| ⑧ | USB 2.0 host port |
| ⑨ | Ethernet management RJ-45 port |
