Overview
Cisco Catalyst C9300-24UX-A is a high-performance enterprise-class access switch designed for next-generation campus networks, WiFi 6/6E deployments, and high-density enterprise environments. Equipped with 24 multigigabit UPOE ports supporting speeds from 100M to 10G, this switch delivers outstanding flexibility, security, and scalability for modern digital infrastructure.
Built on Cisco’s advanced Catalyst 9300 platform, the C9300-24UX-A provides enhanced Layer 2 and Layer 3 capabilities, StackWise-480 technology, advanced security functions, and Network Advantage licensing for enterprise-grade network management and automation.
Quick Specifications
| Specification |
Details |
| Model |
C9300-24UX-A |
| Product Series |
Cisco Catalyst 9300 |
| Ports |
24 x Multigigabit Ethernet Ports |
| Port Speed |
100M/1G/2.5G/5G/10G |
| PoE Support |
Cisco UPOE |
| Switching Capacity |
640 Gbps |
| Stacking Bandwidth |
480 Gbps |
| License |
Network Advantage |
| Layer Support |
Layer 2 / Layer 3 |
| Uplink Options |
1G / 10G / 25G / 40G |
| Power Supply |
1100W AC |
| Mounting |
Rack Mountable |
Key Features of Cisco C9300-24UX-A
1. High-Speed Multigigabit Connectivity
Supports 24 multigigabit ports with speeds up to 10Gbps, making it ideal for WiFi 6/6E access points, high-speed workstations, and bandwidth-intensive applications.
2. Cisco UPOE Power Delivery
Provides Cisco Universal Power over Ethernet (UPOE) support for powering IP phones, wireless access points, IoT devices, and surveillance systems through a single cable.
3. Enterprise-Class Security
Integrated advanced security capabilities including:
- Secure Boot
- MACsec Encryption
- Trustworthy Systems
- Advanced Access Control Lists (ACLs)
- Segmentation and policy enforcement
4. Flexible StackWise-480 Technology
Supports up to 480Gbps stacking bandwidth for simplified management and high availability.
5. Optimized for WiFi 6 and Hybrid Work
The Catalyst 9300 platform is specifically designed for modern wireless environments and cloud-managed enterprise networks.
Technical Specifications
| Feature |
Specification |
| Switching Capacity |
640 Gbps |
| Forwarding Rate |
476.19 Mpps |
| MAC Address Table |
32,000 Entries |
| IPv4 Routing Entries |
32,000 |
| IPv6 Routing Entries |
16,000 |
| VLAN IDs |
4094 |
| Jumbo Frames |
9198 Bytes |
| QoS Support |
Yes |
| Routing Protocols |
OSPF, BGP, EIGRP, RIP, HSRP |
| StackPower Support |
Yes |
| StackWise Support |
StackWise-480 |
| Operating System |
Cisco IOS XE |
| Dimensions |
1U Rack Mount |
Why Choose Cisco C9300-24UX-A?
The Cisco C9300-24UX-A is an excellent choice for enterprises that require:
- High-speed multigigabit switching
- Reliable UPOE support
- Scalable campus network architecture
- Secure enterprise access switching
- WiFi 6/6E infrastructure readiness
- Advanced Layer 3 routing and automation
Compared with traditional Gigabit switches, the C9300-24UX-A delivers significantly higher bandwidth and better support for modern wireless and IoT environments.
C9300-24UX-A vs C9300-24P-A
| Feature |
C9300-24UX-A |
C9300-24P-A |
| Port Speed |
Up to 10G Multigigabit |
1G Gigabit |
| PoE Type |
UPOE |
PoE+ |
| Wireless Optimization |
WiFi 6/6E Ready |
Standard Enterprise |
| Best Use Case |
High-density networks |
Traditional office access |
| Performance |
Higher throughput |
Standard throughput |
The C9300-24UX-A is better suited for organizations deploying high-speed wireless access points and bandwidth-intensive applications.
Typical Application Scenarios
- Enterprise Campus Networks
- WiFi 6 / WiFi 6E Deployments
- Smart Office Infrastructure
- High-Speed Data Access Layer
- IP Surveillance Systems
- IoT Deployments
- Cloud-Managed Enterprise Networks
Frequently Asked Questions (FAQ)
What does “Network Advantage” mean in C9300-24UX-A?
Network Advantage is Cisco’s advanced software license that enables enhanced Layer 3 routing, SD-Access features, automation, and advanced security functions.
Does the C9300-24UX-A support 10G Ethernet?
Yes. All 24 ports support multigigabit speeds up to 10Gbps.
Is the C9300-24UX-A suitable for WiFi 6 access points?
Yes. This switch is specifically optimized for high-speed WiFi 6 and WiFi 6E wireless deployments.
What is the difference between UPOE and PoE+?
UPOE provides higher power delivery compared to standard PoE+, allowing support for power-hungry devices such as advanced wireless APs, PTZ cameras, and collaboration devices.
Can multiple Catalyst 9300 switches be stacked together?
Yes. The switch supports Cisco StackWise-480 technology with up to 480Gbps stacking bandwidth.
Does this switch include uplink modules?
Uplink modules are optional and can support 1G, 10G, 25G, or 40G connectivity depending on deployment requirements.
Is the product original and covered by warranty?
Yes. Original Cisco products typically include serial verification and manufacturer warranty support. Seller warranty and technical support policies may vary.
After-Sales Service & Support
We provide:
- Fast global shipping
- Professional technical support
- Secure packaging
- Product testing before shipment
- Flexible payment methods
- Warranty support
- Bulk order discounts for distributors and integrators
Conclusion
The Cisco C9300-24UX-A Catalyst 9300 switch is a future-ready enterprise networking solution that combines multigigabit performance, UPOE power delivery, advanced security, and scalable stacking technology. It is ideal for enterprises upgrading to WiFi 6, smart office infrastructure, and high-performance campus networks. With advanced Network Advantage licensing and Cisco reliability, the C9300-24UX-A offers long-term value for demanding enterprise environments.
