Product Details:
|
| Model: | ISR4431-VSEC/K9 | Aggregate Throughput: | 500Mbps To 1Gbps |
|---|---|---|---|
| SFP-based Ports: | 4 | Default Flash Memory: | 8 GB |
| Maximum Flash Memory: | 32 GB | Dimensions: | 43.9 X 438.15 X 507.2 Mm |
| Condition: | Brand New | Warranty: | 1 Year |
| Payment: | TT, Western Union, Paypal | Lead Time: | 1-2 Days |
| Shipping: | 5-7 Days | Transportation: | DHL, Fedex, UPS |
| Highlight: | Cisco ISR 4431 Bundle,ISR4431-VSEC/K9,Cisco 4000 Series Industrial Network Router |
||
Cisco 4431 Integrated Services Router, which supports 3 Network Interface Modules (NIM) slots, delivers 500 Mbps to 1 Gbps aggregate throughput. This router also supports two kinds of DDRM, data plane and control/services plane, which make administrator easy to manage the router. ISR4431-VSEC/K9 is the Cisco ISR 4431 Bundle with UC & Sec Lic. PVDM4-64. CUBE-25.
| Models | ISR4431-VSEC/K9 | ISR4431/K9 |
| Aggregate Throughput | 500 Mbps to 1 Gbps | 500 Mbps to 1 Gbps |
|
Total onboard WAN or LAN 10/100/1000 ports |
4 | 4 |
| RJ-45-based ports | 4 | 4 |
| SFP-based ports | 4 | 4 |
| Enhanced service-module slots | 0 | 0 |
| NIM slots | 3 | 3 |
| Onboard ISC slot | 1 | 1 |
| Rack height | 1 | 1 |
ISR4431-VSEC/K9 Specification |
|
| Description | Cisco ISR 4431 Bundle with UC & Sec Lic. PVDM4-64. CUBE-25 |
| Aggregate Throughput | 500Mbps to 1Gbps |
| Total onboard WAN or LAN 10/100/1000 ports | 4 |
| RJ-45-based ports | 4 |
| SFP-based ports | 4 |
| Enhanced service-module slots | 0 |
| Doublewide service-module slots | 0 |
| NIM slots | 3 |
| OIR (all I/O modules) | Yes |
| Onboard ISC slot | 1 |
|
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control/services/data planes) |
NA |
| Maximum memory DDR3 ECC DRAM (Combined control/services/data planes) | NA |
| Default memory DDR3 ECC DRAM (data plane) | 2 GB |
| Maximum memory DDR3 ECC DRAM (data plane) | 2 GB |
| Default memory DDR3 ECC DRAM (control/services plane) | 4 GB |
| Maximum memory DDR3 ECC DRAM (control/services plane) | 16 GB |
| Default flash memory | 8 GB |
| Maximum flash memory | 32 GB |
| External USB 2.0 slots (type A) | 2 |
| USB console port -type B mini (up to 115.2 kbps) | 1 |
| Serial console port - RJ45 (up to 115.2 kbps) | 1 |
| Serial auxiliary port - RJ45 (up to 115.2 kbps) | 1 |
| Power-supply options | Internal: AC, DC, and PoE |
| Redundant power supply | Internal: AC, DC, and PoE |
| AC input voltage | 100 to 240 VAC autoranging |
| AC input frequency | 47 to 63 Hz |
| AC input current range, AC power supply (maximum) | 3 to 1.3A |
| AC input surge current | 60 A peak and less than 5 Arms per half cycle |
| Typical power (no modules) (watts) | 65 |
| Maximum power with AC power supply (watts) | 250 (no PoE) |
| Maximum power with PoE power supply (platform only) (watts) | 500 with PoE redundant |
| Maximum endpoint PoE power available from PoE power supply (watts) | 250 W with optional redundancy |
