Product Details:
|
| Product Type:: | Huawei Network Switch | Model: | S6720S-16X-LI-16S-AC |
|---|---|---|---|
| Ports: | 16 X 10 GE SFP+ Ports | Power Supply: | AC Power Supply |
| Switching Capacity: | 1.28 Tbit/s | Warranty: | New Original With 1 Year |
| High Light: | gigabit network switch,huawei ethernet switches |
||
Huawei S6720S-16X-LI-16S-AC is the Huawei S6720-LI series switch, providing 16 10 Gig SFP+ and AC 110/220V. The S6720-LI series switches (S6720-LI) are next-generation simplified 10GE fixed switches and can be used as 10GE access switches on campus networks and data center networks. The S6720-LI provides line-rate 10GE access ports and 40GE uplink ports. In addition, the S6720-LI delivers a wide variety of services, comprehensive security control policies, and various QoS features to help customers build scalable, reliable, manageable, and secure campus and data center networks.
Note:
| ① | Sixteen 10GE SFP+ ports |
| ② | PNP button |
| ③ | ETH management port |
| ④ | USB port |
| ⑤ | One console port |
Note:
| ① | Ground screw |
| ② | RPS socket |
| ③ | Jack for AC power cable locking strap |
| ④ | AC socket |
shows the recommended products.
| Model | Description |
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.5km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC) |
| eSFP-GE-ZX100-SM1550 | eSFP, GE, Single-mode Module (1550nm, 100km, LC) |
| SFP-GE-LX-SM1310-BIDI | BiDi Transceiver, eSFP, Tx1310nm/Rx1490nm, 1.25Gb/s, -9dBm, -3dBm, -19.5dBm, LC, SM, 10km |
| SFP-GE-LX-SM1490-BIDI | BiDi Transceiver, eSFP, Tx1490nm/Rx1310nm, 1.25Gb/s, -9dBm, -3dBm, -19.5dBm, LC, SM, 10km |
| SFP-GE-ZBXD1 | Huawei Optical Transceiver SFP-GE-ZBXD1, eSFP, GE, BIDI Single-mode Module (1570nm (Tx)/1490nm (Rx), 80km, LC) |
shows the comparison.
| Model | S6720S-16X-LI-16S-AC | S6720S-26Q-LI-24S-AC |
| Ports | 16 x 10 GE SFP+ ports | 24 x 10 GE SFP+ ports, 2 x 40 GE QSFP+ ports |
| Power | Built-in AC power supply and Redundant Power Supply (RPS) | Built-in AC power supply and RPS |
| Packet forwarding rate | 240 Mpps | 240 Mpps |
| Switching capacity | 1.28 Tbit/s | 1.28 Tbit/s |
