Product Details:
|
HAT5300 HDD offers class-leading performance thanks to tight integration with DSM and Synology hardware. With over 300,000 hours of in-house validation testing and backed by Synology’s 5-year limited warranty, the HAT5300 series brings unmatched reliability to Synology deployments.
| Product Code | HAT5300 16T |
| Capacity | 16 TB |
| Form Factor | 3.5" |
| Interface | SATA 6 Gb/s |
| Sector Size | 512e |
| Rotational Speed | 7,200 rpm |
| Interface Speed | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s |
| Buffer Size | 512 MiB |
| Maximum Sustained Data Transfer Speed (Typ.) | 262 MiB/s |
| Mean Time to Failure (MTTF) | 2.5 million hours |
| Workload Rating | 550 TB Transferred per Year |
| Warranty | 5 Years |
| Supply Voltage | 12 V (±10%) / 5 V (+10/-7%) |
| Active Idle (Typ.) | 4.00 W |
| Random Read / Write (4KB Q1) (Typ.) | 7.63 W |
| Size (Height x Width x Depth) | 26.1 mm x 101.85 mm x 147 mm |
| Weight |
720 g
|
HAT5300-16T Specification |
|
| General | |
| Capacity | 16 TB |
| Form Factor | 3.5" |
| Interface | SATA 6 Gb/s |
| Sector Size | 512e |
| Performance | |
| Rotational Speed | 7,200 rpm |
| Interface Speed | 6.0 Gb/s, 3.0 Gb/s, 1.5 Gb/s |
| Buffer Size | 512 MiB |
| Maximum Sustained Data Transfer Speed (Typ.) | 262 MiB/s |
| Reliability | |
| Mean Time to Failure (MTTF) | 2.5 million hours |
| Workload Rating | 550 TB Transferred per Year |
| Warranty | 5 Years |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. |
| Power Consumption | |
| Supply Voltage | 12 V (±10%) / 5 V (+10/-7%) |
| Active Idle (Typ.) | 4.00 W |
| Random Read / Write (4KB Q1) (Typ.) | 7.63 W |
| Notes | Power consumption may differ according to configurations and platforms. |
| Temperature | |
| Operating | 5°C to 60°C (41°F to 140°F) |
| Non-operating | -40°C to 70°C (-40°F to 158°F) |
| Shock | |
| Operating | 686 m/s2 {70 G} (2 ms duration) |
| Non-operating | 2,450 m/s2 {250 G} (2 ms duration) |
| Vibration | |
| Operating | 7.35 m/s2 {0.75 G} (5 to 300Hz), 2.45 m/s2 {0.25 G} (300 to 500 Hz) |
| Non-operating | 29.4 m/s2 {3.0 G} (5 to 500 Hz) |
| Altitude | |
| Operating | -305 m to 3,048 m |
| Non-operating | -305 m to 12,192 m |
| Relative Humidity | |
| Operating | 5% to 90% R.H. (No condensation) |
| Non-operating | 5% to 95% R.H. (No condensation) |
| Others | |
| Size (Height x Width x Depth) | 26.1 mm x 101.85 mm x 147 mm |
| Weight | 720 g |
| Certification |
CE EAC BSMI RCM KC ICES UKCA TUV UL RoHS |
