Huawei CloudEngine 8800 series switches are 100G Ethernet switches designed for data centers and high-end campus networks. The switches provide high-performance, high-density 100GE/40GE/25GE/10GE ports, and low latency. Using the Huawei VRP8 software platform, CloudEngine 8800 series switches provide extensive data center service features and high stacking capability. In addition, the airflow direction (front-to-back or back-to-front) can be changed.
CE8861-4C-EI Switch Specifications
| Ports |
4 slots; combinations of different boards allow you to get: 32 ports 100 GE QSFP28 or 64 ports 40 GE QSFP+ or 128 ports 25 GE SFP28 or 128 ports 10 GE SFP+ or 96 ports 4/8/16 GE FC |
| Switching capacity | 6.4 Tbps (switching capacity after stacking: 57.6 Tbps) |
| Transmission speed | 2,030 million packets per second |
| Buffer | 32 MB |
| Reliability |
LACP Hardware bidirectional transmission detection Microsegmentation |
| MPLS |
L3VPN VPLS |
| O&M |
Telemetry technology Netstream sFlow Enhanced ERSPAN IOAM/INT |
| Data center characteristics |
VXLAN routing and bridging BGP EVPN iStack M-LAG DCBX PFC ETS |
| Maximum power consumption | 750 W |
| Power supply |
AC: 1200W (120V or 240V) DC: 1200 W (–48 V) High voltage DC: 1200W (240V or 380V) |
| Operating voltage |
AC current: 90 to 290 V Direct current: –38.4 to 72 V High voltage DC: 188 to 290 V (at 240 V); from 188 to 400 V (at 380 V) |
