| Place Of Origin: | USA | Model: | EX3400 24T |
|---|---|---|---|
| Keyword: | Fiber Optic Transceiver | Product: | Cisco Wireless Lan Controllers |
| Discription: | Sfp Transceiver Modules | Shipping: | DHL FEDEX |
| Lead Time: | 1-2 Working Days | MOQ: | 1pcs |
| High Light: | Optic Fiber Poe Ethernet Switch,24T Cisco Ethernet Switch,Poe Optical Fiber Switch |
||
EX3400-24T EX3400 Cisco Ethernet Switch original networking poe ethernet switch optic fiber
(fiber optic transceiver cisco wireless lan controllers sfp transceiver modules)
EX3400-24T Overview
EX3400-24T is a Juniper EX3400 switch with 24-port 10/100/1000BASE-T with 4 SFP+ and 2 QSFP+ uplink ports (optics not included). EX3400 Ethernet Switches are a cost-effective solution for today’s most demanding converged video enterprise access networks. The compact, fixed-configuration 1U devices offer levels of performance and management previously available only with high-end access switches.
| SKU | EX3400-24T |
| Ports | 24-port 10/100/1000BASE-T with 4 SFP+ and 2 QSFP+ uplink ports (optics not included) |
| Data rate | 288 Gbps |
| Throughput | 214 Mpps (wire speed) |
| Dimensions (W x H x D) | 17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit |
EX3400-24T Specification |
|
| Description | EX3400 24-port 10/100/1000BASE-T with 4 SFP+ and 2 QSFP+ uplink ports (optics not included) |
| Form factor | Fixed platform Virtual Chassis configuration consisting of up to 10 switches Junos Fusion Enterprise Satellite device |
| Dimensions (W x H x D) | 17.4 x 1.7 x 13.8 in (43.7 x 4.4 x 35 cm) 1 rack unit |
| Backplane speed | 160 Gbps |
| Data rate | 288 Gbps |
| 100GBASE C form-factor pluggable transceiver (CFP) port densities | N/A |
| Resiliency | Redundant, field-replaceable power supplies Redundant trunk groups that provide port redundancy and simplify switch configuration |
| Operating system | Junos OS |
| Traffic monitoring | sFlow |
| Quality-of-service (QoS) queues/port | 8 unicast/4 multicast |
| MAC addresses | 32,000 |
| Jumbo frames | 9216 bytes |
| IPv4 unicast/multicast routes | 36,000/4,000 |
| IPv6 unicast/multicast routes | 18,000/2,000 |
| Number of VLANs | 4,096 |
| ARP entries | 16,000 |
