Product Details:
|
| Brand: | Cisco | Parts Number: | A9K-MPA-8X10GE |
|---|---|---|---|
| Uplink Configuration: | 8 X 10G SFP+ | Protocols: | 10 Gigabit Ethernet |
| Condition: | In Stock | Shipment: | DHL,UPS,TNT, |
| High Light: | cisco router switch module,cisco service module |
||
The Cisco® ASR 9000 Series modular line cards provide customers with a flexible solution supporting multiple combinations of Ethernet ports, all in a single slot of the Cisco ASR 9000 Series Aggregation Services Routers. Modular line cards support a wide range of interfaces and densities.
Using the modular line cards, the Cisco ASR 9000 Series can support customer applications including video-on-demand, Internet Protocol Television (IPTV), point-to-point video, Internet video, and cloud-based computing. These line cards can also be used to deliver economical, scalable, highly available, line-rate Ethernet and IP/Multiprotocol Label Switching (IP/MPLS) edge services. The Cisco ASR 9000 Series line cards and routers are designed to provide the fundamental infrastructure for scalable Carrier Ethernet and IP/MPLS networks, supporting profitable business, residential, and mobile services
Product Details
|
Description |
Specification |
|---|---|
| Chassis compatibility | Compatible with the Cisco ASR 9922, 9010, 9006 and 9001 systems |
| Port density | Up to 2 modular port adapters are supported per line card.. |
| Ethernet |
● IEEE 802.3 compliant
● 10 Gigabit Ethernet PHY monitoring
● IEEE 802.x flow control
● Full-duplex operation
● Per-port byte and packet counters for policy drops; oversubscription drops; cyclic redundancy check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets
|
| Card density | Maximum number of line cards per system: Cisco ASR 9922 = 20, Cisco ASR 9010 = 8, and Cisco ASR 9006 = 4 |
| Options |
Each line card is available as either a Service Edge Optimized (enhanced QoS) or Packet Transport Optimized (basic QoS) line card. |
| Reliability and availability | Line card online insertion and removal (OIR) support without system impact |
| Network Equipment Building Standards (NEBS) |
Cisco ASR 9000 Series Routers are designed to meet: ● SR-3580: NEBS Criteria Levels (Level 3)
● GR-1089-CORE: NEBS EMC and Safety
● GR-63-CORE: NEBS Physical Protection
|
| Operating temperature (nominal) | 41 to 104ºF (5 to 40ºC) |
| Operating temperature (short-term) |
23 to 131ºF (–5 to 55ºC) |
| Operating humidity (nominal) relative humidity | 10 to 85% |
| Storage temperature | –40 to 158ºF (–40 to 70ºC) |
| Storage relative humidity |
5 to 95% Note: Not to exceed 0.024 kg of water per kg of dry air |
| Operating altitude | –60 to 4000m (up to 2000m conforms to IEC, EN, UL, and CSA 60950 requirements) |
