Cisco Switch N9K-C9372PX-E Nexus 9000 Series Switch 48p 10G SFP+ And 6p 40G QSFP+

Cisco Switch N9K-C9372PX-E  Nexus 9000 Series Switch 48p 10G SFP+ And 6p 40G QSFP+
Cisco Switch N9K-C9372PX-E  Nexus 9000 Series Switch 48p 10G SFP+ And 6p 40G QSFP+

Large Image :  Cisco Switch N9K-C9372PX-E Nexus 9000 Series Switch 48p 10G SFP+ And 6p 40G QSFP+

Product Details:
Place of Origin: CHINA
Brand Name: CISCO
Certification: CE
Model Number: N9K-C9372PX-E
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: Negotiable
Packaging Details: NEW IN BOX
Delivery Time: 1-2 DAYS
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 50 UNITS/MONTH

Cisco Switch N9K-C9372PX-E Nexus 9000 Series Switch 48p 10G SFP+ And 6p 40G QSFP+

Description
Part Number: N9K-C9372PX-E Brand: CISCO
Typical Power*(AC & DC): 210W Maximum Power* (AC & DC): 537W
Input Voltage (AC): 100 To 240V Nput Voltage (HVAC): 200 To 277V
High Light:

optical ethernet switch

,

poe ethernet switch





N9K-C9372PX-E Cisco Nexus 9000 Series Switch 48p 10G SFP+ and 6p 40G QSFP+




N9K-C9372PX-E Overview



Cisco Nexus 9372PX-E Switch (N9K-C9372PX-E) is a minor hardware revision of the Cisco Nexus 9372PX. Enhancements include hardware capability for IP-based endpoint group (EPG) classification in Cisco ACI mode.





Cisco Switch N9K-C9372PX-E  Nexus 9000 Series Switch 48p 10G SFP+ And 6p 40G QSFP+ 0





N9K-C9372PX-E Specification



N9K-C9372PX-E Specification

Ports 48 fixed 1/10-Gbps SFP+ and 6 QSFP+ ports
Supported speeds 1/10 Gigabit Ethernet speeds
40 Gigabit Ethernet uplink port 6 fixed QSFP+ ports
Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber.
The switch offers 25 MB of additional packet buffer space shared with all ports for more resilient operations.
Power supplies (up to 2) 650W AC, 930W DC, or 1200W HVAC/HVDC
Typical power*(AC & DC) 210W
Maximum power* (AC & DC) 537W
Input voltage (AC) 100 to 240V
Input voltage (HVAC) 200 to 277V
Input voltage (DC)

-40V to -72V DC (min-max)

-48V to -60V DC (nominal)

Input voltage (HVDC) –240 to –380V
Frequency (AC) 50 to 60 Hz
Fans 4
Physical (H x W x D) 1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm)
Acoustics 48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dB at 100% fan speed
RoHS compliance Yes
Maximum number of longest prefix match (LPM) routes 128,000*
Maximum number of IP host entries 208,000*
Maximum number of MAC address entries 96,000*
Number of multicast routes

● 32,000 (without virtual PortChannel [vPC])

● 32,000 (with vPC)

Number of Interior Gateway Management Protocol (IGMP) snooping groups

● 32,000 (without vPC)

● 32,000 (with vPC)

Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch 16
Number of access control list (ACL) entries

● 4000 ingress

● 1000 egress

Maximum number of VLANs 4096
Maximum number of Virtual Routing and Forwarding (VRF) instances 1000
Maximum number of links in a PortChannel 32
Maximum number of ECMP paths 64
Maximum number of PortChannels 528
Number of active SPAN sessions 4
Maximum number of Rapid per-VLAN Spanning Tree (RPVST) instances 507
Maximum number of Hot-Standby Router Protocol (HSRP) groups 490
Maximum number of Multiple Spanning Tree (MST) instances 64
Maximum number of VXLAN tunnel endpoints (VTEP) 256
Environmental Properties
Operating temperature 32 to 104°F (0 to 40°C)
Nonoperating (storage) temperature -40 to 158°F (-40 to 70°C)
Humidity 5 to 95% (noncondensing)
Altitude 0 to 13,123 ft (0 to 4000m)
Weight
Cisco Nexus 9372PX/9372PX-E without power supplies or fans 22.2 lb (10.1 kg)
Cisco Nexus 9372TX/9372TX-E without power supplies or fans 22.6 lb (10.25 kg)
Safety and EMC
Regulatory compliance Products should comply with CE Markings according to directives 2004/108/EC and 2006/95/EC
Safety

● UL 60950-1 Second Edition

● CAN/CSA-C22.2 No. 60950-1 Second Edition

● EN 60950-1 Second Edition

● IEC 60950-1 Second Edition

● AS/NZS 60950-1

● GB4943

EMC: Emissions

● 47CFR Part 15 (CFR 47) Class A

● AS/NZS CISPR22 Class A

● CISPR22 Class A

● EN55022 Class A

● ICES003 Class A

● VCCI Class A

● EN61000-3-2

● EN61000-3-3

● KN22 Class A

● CNS13438 Class A

EMC: Immunity

● EN55024

● CISPR24

● EN300386

● KN 61000-4 series

RoHS The product is RoHS-6 compliant with exceptions for leaded-ball grid-array (BGA) balls and lead press-fit connectors
