N9K-C93108TC-FX Overview
The Cisco N9K-C93108TC-FX Switch is a 1RU switch that supports 2.16 Tbps of bandwidth and over 1.25bpps. The 48 10GBASE-T downlink ports on the 93108TC-FX can be configured to work as 100-Mbps, 1-Gbps, or 10-Gbps ports. The uplink can support up to six 40- and 100-Gbps ports, or a combination of 1-, 10-, 25-, 40, 50-, and 100-Gbps connectivity, offering flexible migration options.
Quick Specs
Table 1 shows the Specs.
SKU |
N9K-C93108TC-FX |
CPU |
4 cores |
System memory |
24 GB |
SSD drive |
128 GB |
System buffer |
40 MB |
Management ports |
2 ports: 1 RJ-45 and 1 SFP+ |
USB ports |
1 |
RS-232 serial ports |
1 |
Power supplies (up to 2) |
500W AC, 930W DC, or 1200W HVAC/HVDC |
RS-232 serial ports |
1 |
Product Details
Cisco N9K-C93108TC-FX provides the following features:
①Architectural Flexibility
②Architectural Flexibility
③High Scalability, Flexibility, and Security
④Intelligent Buffer Management
⑤RDME over Converged Ethernet – RoCE Support
⑥LAN and SAN Convergence
⑦Hardware and Software High Availability
⑧Purpose-Built Cisco NX-OS Software Operating System with Comprehensive, Proven Innovations
⑨Cisco Tetration Analytics Platform Support
⑩Cisco Network Assurance Engine (NAE)
Compare to Similar Items
Table 2 shows the comparison.
Product Name |
N9K-C93108TC-FX |
N9K-C93180YC-FX |
N9K-C9348GC-FXP |
Ports |
48 x 100M/1/10GBASE-T and 6 x 40/100-Gbps QSFP28 ports |
48 x 1/10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports |
48 x 1-GBASE-T ports, 4 x 1/10/25-Gbps SFP28 ports and 2 x 40/100 QSFP28 ports |
CPU |
4 cores |
6 cores |
4 cores |
System memory |
24 GB |
Up to 32 GB |
24 GB |
SSD drive |
128 GB |
128 GB |
128 GB |
System buffer |
40 MB |
40 MB |
40 MB |
USB ports |
1 |
1 |
1 |
RS-232 serial ports |
1 |
1 |
1 |
N9K-C93108TC-FX Specification
N9K-C93108TC-FX Specification
|
Hardware performance and scalability |
Ports |
48 x 100M/1/10GBASE-T and 6 x 40/100-Gbps QSFP28 ports |
Downlink supported speeds |
100-Mbps and 1/10-Gbps speeds |
CPU |
4 cores |
System memory |
24 GB |
SSD drive |
128 GB |
System buffer |
40 MB |
Management ports |
2 ports: 1 RJ-45 and 1 SFP+ |
USB ports |
1 |
RS-232 serial ports |
1 |
Power supplies (up to 2) |
500W AC, 930W DC, or 1200W HVAC/HVDC |
Typical power (AC/DC) |
276W |
Maximum power (AC/DC) |
460W |
Input voltage (AC) |
100 to 240V |
Input voltage
(High-Voltage AC [HVAC]) |
200 to 277V |
Input voltage (DC) |
–48 to –60V |
Input voltage
(High-Voltage DC [HVDC]) |
–240 to –380V |
Frequency (AC) |
50 to 60 Hz |
Fans |
4 |
Airflow |
Port-side intake and exhaust |
Physical dimensions
(H x W x D) |
1.72 x 17.3 x 22.5 in.
(4.4 x 43.9 x 57.1 cm) |
Acoustics |
64.2 dBA at 40% fan speed, 68.9 dBA at 70% fan speed, and 77.8 dBA at 100% fan speed |
RoHS compliance |
Yes |
MTBF |
319,790 hours |
Environmental properties |
Operating temperature |
32 to 104°F (0 to 40°C) |
Nonoperating (storage) temperature |
–40 to 158°F (–40 to 70°C) |
Humidity |
5 to 95% (noncondensing) |
Altitude |
0 to 13,123 ft (0 to 4000m) |
S5735-L24P4S-A Overview
Establish Fast and Easy-to-use Network by Powerful Switches.
Choose top branded switches to accelerate your business, including Cisco, Huawei, Juniper, etc.
S5735-L24P4S-A is the Huawei S5735-L switch with 24 x 10/100/1000Base-T ports, 4 x GE SFP ports, PoE+. Huawei CloudEngine S5735-L is a series of simplified gigabit access switches that provide 12–48 flexible all-GE downlink ports and four fixed GE or 10 GE uplink ports. They are designed for enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and powered by Huawei’s Versatile Routing Platform (VRP), CloudEngine S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols — providing higher performance and more powerful service processing capabilities for networks.
Quick Spec
Table 1 shows the quick spec.
Product Model |
S5735-L24P4S-A |
Forwarding Performance |
42 Mpps |
Switching Capacity2 |
56 Gbit/s/336 Gbit/s |
Fixed Ports |
24 x 10/100/1000Base-T ports, 4 x GE SFP ports |
PoE+ |
Supported |
Product Details
Figure 1 shows the front ports of S5735-L24P4S-A.
Note:
① |
24 10/100/1000BASE-T ports |
④ |
One PNP button |
② |
Four 1000BASE-X ports |
⑤ |
One USB port |
③ |
One ETH management port |
⑥ |
One console port |
Figure 2 shows the back view of S5735-L24P4S-A.
Note:
① |
Ground screw |
② |
Jack for AC power cable locking strap |
③ |
AC socket |
Supported Transceivers
Table 2 shows the recommended models.
Model |
Description |
OMXD30000 |
Huawei Optical Transceiver OMXD30000, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
OSX010000 |
Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
SFP-GE-LX-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
OSXD22N00 |
Optical Transceiver, SFP+, 10G, Multi-mode Module (1310nm, 0.22km, LC, LRM) |
SFP-10G-USR |
10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
OMXD30009 |
Transceiver, QSFP+, 1310nm, 41.25Gbps, -7dBm, 2.3dBm, -11.5dBm, LC, SMF, 10 |
SFP-10G-LR |
Huawei Optical Transceiver SFP-10G-LR, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
Compare to Similar Items
Table 3 shows the comparison.
Product Model |
S5735-L12T4S-A
S5735-L12P4S-A
|
S5735-L24T4S-A
S5735-L24P4S-A
|
S5735-L24T4X-A
S5735-L24P4X-A
|
S5735-L48T4S-A |
S5735-L48T4X-A
S5735-L48P4X-A
|
S5735-L32ST4X-A |
Forwarding Performance |
24 Mpps |
42 Mpps |
96 Mpps |
78 Mpps |
132 Mpps |
108 Mpps |
Switching Capacity2 |
32 Gbit/s/336 Gbit/s |
56 Gbit/s/336 Gbit/s |
128 Gbit/s/336 Gbit/s |
104 Gbit/s/432 Gbit/s |
176 Gbit/s/432 Gbit/s |
144 Gbit/s/432 Gbit/s |
Fixed Ports |
12 x 10/100/1000Base-T ports, 4 x GE SFP ports |
24 x 10/100/1000Base-T ports, 4 x GE SFP ports |
24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports |
48 x 10/100/1000BASE-T ports, 4 x GE SFP ports |
48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports |
24 x GE SFP ports, 8 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports |
PoE+ |
CloudEngine S5735-L12P4S-A: Supported
CloudEngine S5735-L24P4S-A: Supported
CloudEngine S5735-L24P4X-A: Supported
CloudEngine S5735-L48P4X-A: Supported
Other: Not supported |
Get More Information
Do you have any question about the S5735-L24P4S-A?
Contact us now via Live Chat or sales@router-switch.com.
we also have Alibaba shop: you can click it . https://shuaiqicn.en.alibaba.com/?spm=a2700.7756200.0.0.fea571d2uK6of4
S5735-L24P4S-A Specification
S5735-L24P4S-A Specification
|
Forwarding Performance |
42 Mpps |
Switching Capacity2 |
56 Gbit/s/336 Gbit/s |
Fixed Ports |
24 x 10/100/1000Base-T ports, 4 x GE SFP ports |
PoE+ |
Supported |
MAC Features |
MAC address auto-learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
Interface-based MAC address learning limiting |
VLAN Features |
4094 VLANs
Guest VLAN, Voice VLAN
GVRP
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
1:1 and N:1 VLAN mapping |
IP Routing |
Static route, RIP, RIPng, OSPF, OSPFv3 |
Super Virtual Fabric (SVF) |
Plug-and-play SVF clients
Automatic software package and patch loading to SVF clients
One-click and automatic delivery of service configurations
Independent SVF client operations |
Interoperability |
VBST (compatible with PVST/PVST+/RPVST)
LNP (similar to DTP) |
