Product Details:
|
| Brand: | Cisco | Typical Operating Power: | 102W |
|---|---|---|---|
| Maximum Power: | 193W | System Memory: | 16 GB |
| Condition: | New With 1Year Replacement Warranty | Shipment: | DHL,UPS,TNT, |
| High Light: | C1000-16T-2G-L Ethernet Network Switch,2x1G SFP Ethernet Network Switch,102W 16 Gigabit Ethernet Network Switch |
||
Table 1 shows the Quick Specs.
| Product Code | C1000-16T-2G-L |
| Description | 16x 10/100/1000 Ethernet ports, 2x 1G SFP uplinks |
| Gigabit Ethernet ports | 16 |
| Uplink interfaces | 2 SFP |
| PoE+power budget | |
| Fanless | Y |
| Dimensions (WxDxH in inches) | 10.56 x 10.69 x 1.73 |
| CPU | ARM v7 800 MHz |
| DRAM | 512 MB |
| Flash memory | 256 MB |
| Forwarding bandwidth | 18 Gbps |
| Switching bandwidth | 36 Gbps |
| Forwarding rate(64—byte L3 packets) | 26.78 Mpps |
The Cisco Catalyst 1000 Series Switches provides these features:
* 8, 16, 24, or 48 Gigabit Ethernet data or PoE+ ports with line-rate forwarding
* 2 or 4 fixed 1 Gigabit Ethernet Small Form-Factor Pluggable (SFP)/RJ 45 Combo uplinks or 4 fixed 0 Gigabit Ethernet Enhanced SFP (SFP+) uplinks
* Perpetual PoE+ support with a power budget of up to 740W
* CLI and/or intuitive web UI manageability options
* Network monitoring through sampled flow (sFlow)
* Security with 802.1X support for connected devices, Switched Port Analyzer (SPAN), and Bridge Protocol Data Unit (BPDU) Guard
* Compact fanless models available with a depth of less than 13 inches (33 cm)
*Device management support with over-the-air access via Bluetooth, Simple Network Management Protocol (SNMP), RJ-45, or USB console access
* Reliability with a higher Mean Time Between Failures (MTBF) and an enhanced limited lifetime warranty support(E-LLW)
Table 2 shows the comparison.
| Product Code | C1000-16T-E-2G-L | C1000-16P-2G-L | C1000-16P-E-2G-L | C1000-16T-2G-L | C1000-16FP-2G-L |
| Description | 16x 10/100/1000 Ethernet ports, 2x 1G SFP uplinks with external PS | 16x 10/100/1000 Ethernet PoE+ ports and 120W PoE budget, 2x 1G SFP uplinks | 16x 10/100/1000 Ethernet PoE+ ports and 120W PoE budget, 2x 1G SFP uplinks with external PS | 16x 10/100/1000 Ethernet ports, 2x 1G SFP uplinks | 16x 10/100/1000 Ethernet PoE+ ports and 240W PoE budget, 2x 1G SFP uplinks |
| Gigabit Ethernet ports | 16 | 16 | 16 | 16 | 16 |
| Uplink interfaces | 2 SFP | 2 SFP | 2 SFP | 2 SFP | 2 SFP |
| PoE+power budget | 120W | 120W | 240W | ||
| Fanless | Y | Y | Y | Y | Y |
| Dimensions (WxDxH in inches) | 10.56 x 8.26 x 1.73 | 10.56 x 11.69 x 1.73 | 10.56 x 8.26x 1.73 | 10.56 x 10.69 x 1.73 | 10.56 x 12.14 x 1.73 |
| CPU | ARM v7 800 MHz | ARM v7 800 MHz | ARM v7 800 MHz | ARM v7 800 MHz | ARM v7 800 MHz |
| DRAM | 512 MB | 512 MB | 512 MB | 512 MB | 512 MB |
| Flash memory | 256 MB | 256 MB | 256 MB | 256 MB | 256 MB |
| Forwarding bandwidth | 18 Gbps | 18 Gbps | 18 Gbps | 18 Gbps | 18 Gbps |
| Switching bandwidth | 36 Gbps | 36 Gbps | 36 Gbps | 36 Gbps | 36 Gbps |
| Forwarding rate(64—byte L3 packets) | 26.78 Mpps | 26.78 Mpps | 26.78 Mpps | 26.78 Mpps | 26.78 Mpps |
