QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module

QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module
QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module

Large Image :  QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module

Product Details:
Place of Origin: China
Brand Name: Compatible module
Certification: CE
Model Number: QSFP+ 40G-IR4-PSM
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: SEALED IN BAG
Delivery Time: 1-2 days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 1000 PCS/MONTH

QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module

Description
Product Model: QSFP+ 40G-IR4-PSM Data Rate: 41.2Gbps
Wavelength: 1310nm Max Cable Distance: 1.4km@SMF
Transimitter Type: DFB CWDM DDM/DOM: Supported
Warranty: 1 Year Warranty L/R PIN: HXQ40PI
High Light:

QSFP+ 40G-IR4-PSM

,

MPO DOM Optical Transceiver Module

,

DFB CWDM Optical Transceiver Module



























Overview



 QSFP+40G-IR4-PSM1310 Compatible QSFP+ Optical Transceiver Module is designed for use in 40GBASE Ethernet throughput up to 1.4km over single mode fiber (SMF) using a wavelength of 1310nm via a MTP/MPO connector. It provides high-density and low-power 40GBASE Ethernet solution for data centers, high-performance computing networks, enterprise core and distribution layer applications. It is fully compliant with the QSFP+ MSA and IEEE 802.3ae 10GBASE-LR/LW standard.





Specification



 Compatible QSFP+40G-IR4-PSM1310 Vendor Name LR
Form Factor QSFP+ Max Data Rate 41.2Gbps
Wavelength 1310nm Max Cable Distance* 1.4km@SMF
Connector MTP/MPO Media SMF
Transimitter Type DFB CWDM Receiver Type PIN
DDM/DOM Supported Commercial Temperature Range 0 to 70°C (32 to 158°F)
TX Power -9.4~0.5dBm Receiver Sensitivity -14.4dBm
Power Consumption 2.5W Extinction Ratio 3.5dB
Modulation Format NRZ CDR None
Transmit and Dispersion Penalty 3.5dB Powerbudget 5dB
Packaging Technology BOX Packaging FEC Function


Supported
Protocols 40Gigabit Ethernet, 38-pin edge connector, MSA Compliant Application 10GBASE-LR Lite 10G Ethernet, Data Center



QSFP+40G-IR4-PSM1310 Compatible 4x10G-IR QSFP+ 1310nm 1.4km MTP/MPO DOM Optical Transceiver Module 0



FAQ



1. How to ship the goods?

Lonrise work with DHL,FEDEX,UPS and TNT. Your order will be dispatched by express delivery door to door.



2. What’s your payment term?

We always accept 10% advance payment. For long term cooperation, we can consider to apply credit accordingly.



Related products

 PN DESCRIPTION DATA RATE REACH   TX  RX OUTPUT POWER SENSITIVITY
HXQ40S QSFP+ SR4 40Gbps 100M 850nm VCSEL PIN -7.6~+2.4dBm ≦-11.1dBm
HXQ40S3 QSFP+ eSR4 40Gbps 300M 850nm VCSEL PIN -7.6~+2.4dBm ≦-11.1dBm
HXQ40CG QSFP+ CWDM GR4 40Gbps 2KM CWDM DFB PIN -7.5~+2.5dBm ≦-10dBm
HXQ40PI QSFP+ PSM IR4 40Gbps 2KM 1310nm DFB PIN -5.5~+1.5dBm ≦-12.5dBm
HXQ40L QSFP+ LR4 40Gbps 10KM CWDM DFB PIN -7.5~+2.5dBm ≦-10dBm
HXQ40Le QSFP+ eSM4 40Gbps 10KM 1310nm DFB PIN -5.5~+1.5dBm ≦-12.6dBm
HXQ40E QSFP+ ER4 40Gbps 40KM CWDM DFB PIN -2.7~+4.5dBm ≦-19dBm
