Product Details:
|
| Brand: | Cisco | Parts Number: | AR550C-2C6GE |
|---|---|---|---|
| Dimensions (W X D X H): | 44 Mm X 133 Mm X 150 Mm | Redundant Power Supplies: | 9.6V To 60V DC |
| High Light: | gigabit network switch,huawei ethernet switches |
||
AR550 series industrial IoT gateway are specially designed for network communication in challenging environments such as extreme temperature, high humidity, and electromagnetic interference. The AR550 series integrates routing, switching, IPSec VPN, and other functions, provides powerful application scalability, and widely applies to various industrial automation fields, such as electric power automation and transportation automation.
|
Specifications |
AR550C-4GE |
AR550C-2C6GE |
AR550-8FE-D-H |
AR550-24FE-D-H |
|
Fixed Ethernet Interfaces |
2 x 2.5G SFP (compatible with GE), |
2 x 2.5G SFP (compatible with GE), |
8 x FE RJ45 + 4 x GE Combo |
24 x FE RJ45 + 4 x GE Combo |
|
4 x GE RJ45 |
2 x GE combo, 6 x GE RJ45 |
|||
|
Forwarding Performance |
13.5 Mpps |
19.5 Mpps |
7.2 Mpps |
9.6 Mpps |
|
Switching Capacity |
128Gbps |
|||
|
Certifications |
CB (IEC 60950) |
|||
|
NRTL (UL60950-1) |
||||
|
EU CE (EN 55022, EN 55024, and EN 300386) |
||||
|
USA FCC (47CFR Part 15) |
||||
|
Canada IC (ICES-003) |
||||
|
Australia C-Tick (AS/NZS CIPSR22) |
||||
|
Electric power IEC61850-3/IEEE1613 (substation) |
||||
|
EN50155 (railway) |
||||
|
Ring Network Protocols |
SEP, STP, RSTP, and MSTP |
|||
|
Power Supply |
Dual DC power: 9.6V to 60V (terminal block) |
|||
|
IP Grade |
IP40 |
|||
|
Operating Temperature |
–40°C to 70°C |
–40°C to 70°C |
||
|
The device is tested for 2 hours at temperatures in the range of 70°C to 85°C |
||||
|
Dimensions |
44 mm x 133 mm x 150 mm |
44 mm x 133 mm x 150 mm |
97 mm x 133 mm x 150 mm |
133 mm x 133 mm x 150 mm |
|
(W x D x H) |
||||
